class: center, middle, inverse, title-slide # Tools, Database, and otherthings you may need to know ## <em>however I don’t have enough time to tell you</em> ### Lijia Yu ### 2019/08/27<br/>(updated: 2019-09-09) --- # Outline 1. Review 2. VarBen --- ### Q1: Write your bioinfomatics research report 1. Executive Summary (\*) - Introduction - Data and Methods - Results 2. Data Mungling 3. Analysis - Step1 - Step 2 4. Appendix (\*) - Working dir - Script descriptions - List of Figures - List of Tables --- ### Q2: Shell programming with BASH (Bourne Again SHell) ```bash #!/bin/bash /home/admin/software/FastQC/fastqc -t 1 \ -o /home/admin/project/out \ --noextract \ -d /home/admin/project/tmp \ -f fastq \ /home/admin/ILLUMINA_FASTQ/cancer_R1.fq.gz \ /home/admin/ILLUMINA_FASTQ/cancer_R2.fq.gz ``` save in `.sh` format. (script.sh) ```bash bash ./src/script.sh ``` .footnote[ [1] [Shell programming with bash: by example, by counter-example](http://matt.might.net/articles/bash-by-example/) [2] **Bash**: <https://en.wikipedia.org/wiki/Bash_(Unix_shell)> ] --- ### Q3: How to tells the Linux system not to stop run the code after I log out? ```bash nohup bash ./src/script.sh > mycommand.out 2> mycommand.err & ``` Alternatives - Screen - Tmux - Disown .footnote[ [1][Unix Nohup: Run a Command or Shell-Script Even after You Logout](https://linux.101hacks.com/unix/nohup-command/) [2][Linux Nohup Command](https://linuxize.com/post/linux-nohup-command/) ] --- ### Q4: How to connect to server or download data from server? - [PuTTY](https://putty.org/) - [xterm](https://invisible-island.net/xterm/) - [iterm2](https://iterm2.com): for macOS - [xshell](https://www.netsarang.com/en/xshell/) - [FileZilla](https://filezilla-project.org/): recommand - [WinSCP](https://winscp.net/eng/index.php) - [Rstudio](https://www.rstudio.com/products/rstudio/download/): recommand ```bash ssh yulijia@192.168.0.105 ``` - Host: 192.168.0.105 - username: yulijia - password: password - port: 22  --- ### Q5: How to install software on Linux server? - C/C++: make & make install - Python/Perl: usually you need to install dependencies and then run the code - Java: usually you just need to make sure you have installed correct JAVA program (version) and then run the downloaded `.jar` package ```bash cd ./toolsA ./configure --prefix=/home/yulijia make make install ``` --- ### Q6: How to determine somatic mutation ? - Germline VAF approximately 50% or 100%. - Somatic mutation related database. - Missense SNV, splicing site. - VAF dramatically difference between control and tumor sample. .footnote[ [1] [standards and guidelines for the interpretation and reporting of sequence variants in cancer](https://www.ncbi.nlm.nih.gov/pubmed/27993330) ] --- ### Q6: How to determine somatic mutation ? (Cont.) .center[  ] .footnote[ [1] [standards and guidelines for the interpretation and reporting of sequence variants in cancer](https://www.ncbi.nlm.nih.gov/pubmed/27993330) ] --- ### Q7: The Integrative Genomics Viewer (IGV) https://software.broadinstitute.org/software/igv/  --- ### Q8: Abbreviations (FASTA, FASTQ, SAM, BAM, VCF) #### FASTA is FAST-all (not abbreviation) #### FASTQ is FASTA + quality (not abbreviation) #### Sequence Alignment Map (SAM) #### Binary Alignment Map (BAM) #### Variant Call Format (VCF) #### Browser Extensible Data (BED) --- ### Q9: Mutation type  --- # VarBen https://github.com/nccl-jmli/VarBen A tool for adding variant simulation to **.bam** files, including single-nucleotide variants, short insertions and deletions, and large structural variants. 1. install dependencies ```bash python2 -m pip install pysam python2 -m pip install numpy git clone https://github.com/samtools/htslib.git make -C htslib git clone https://github.com/samtools/samtools.git make -C samtools cp samtools/samtools $HOME/bin git clone https://github.com/samtools/bcftools.git make -C bcftools cp bcftools/bcftools $HOME/bin git clone https://github.com/lh3/bwa.git make -C bwa cp bwa/bwa $HOME/bin ``` --- # VarBen: edit SNV and Indel |chrom|start|end|allelefrequency|type|alternative| |:----:|:----:|:----:|:----:|:----:|:----:| |chr1|899778|899778|0.9|snv|T| |chr1|1158637|1158638|0.5|ins|TAG| |chr1|6533124|6533126|0.12|del|.| |chr7|55242467|55242481|0.3|Sub|TTC| - `Sub` is complex mutation, begin with capital letter ```bash #chrom start end AF type alt chr1 899778 899778 0.9 snv T chr1 1158637 1158638 0.9 ins TAG chr1 6533124 6533126 0.9 del . #Complex indel format: EGFR, c.2237_2251>TTC(p.E746_T751>VP) chr7 55242467 55242481 0.3 Sub TTC ``` --- # VarBen: muteditor ```bash python2 /opt/VarBen/bin/muteditor.py -m ./mutationFile.txt \ -b ./Illumina_normal.bam \ -r ./reference/hg19/ucsc.hg19.fasta \ -p 4 \ --aligner bwa \ --alignerIndex ./reference/hg19/ucsc.hg19.fasta \ --seqer illumina \ --haplosize 10 \ --mindepth 500 \ --minmutreads 5 \ --snpfrac 0.1 \ -o ./Illumina_mut_out/ ``` - `haplosize`: if the distance of two or more variants is less than 10bp, then the software will consider these variants are happenned on the sample haplotype. - `mindepth`: the minimum read depth on the editing site - `minmutreads`: the minimum mutated read on the editing site - `snpfrac`: the SNP frequency on the editing site, if detecting a frequency large than the variable, then the software will skip the site. --- # VarBen: edit SV - Deletion and Inversion |chrom|start|end|type|AF| |:----:|:----:|:----:|:----:| |chrX|12994966|12996009|del|0.4| |chrX|13703890|14134046|inv|0.8| - Duplication |chrom|start|end|type|AF|dup_num| |:----:|:----:|:----:|:----:|:----:| |chr1|15808448|15814030|dup|0.5|3| --- # VarBen: sveditor ```bash python2 /opt/VarBen/bin/sveditor.py -m ./svFile.txt \ -b ./Illumina_normal.bam \ -r ./reference/hg19/ucsc.hg19.fasta \ --aligner bwa \ --alignerIndex ./reference/hg19/ucsc.hg19.fasta \ --seqer illumina \ --mindepth 100 \ --minmutreads 10 \ -p 12 \ -l 100 \ -o ./sv_out/ ``` - `l`: read length --- # VarBen: edit result  --- background-image: url(https://bedtools.readthedocs.io/en/latest/_static/bedtools.swiss.png) background-size: 90px background-position: 90% 5% # Convert BAM to FASTQ - `bedtools` allows one to intersect, merge, count, complement, and shuffle genomic intervals from multiple files in widely-used genomic file formats such as BAM, BED, GFF/GTF, VCF. ```bash bedtools bamtofastq -i edit.sorted.bam \ -fq ./out/normal_R1.fq \ -fq2 ./out/normal_R2.fq ``` .footnote[ [1] [bedtools: a powerful toolset for genome arithmetic](https://bedtools.readthedocs.io/en/latest/) ] --- # Test 1. a piepline script to call SNV and Indel 2. report (need to include IGV snapshot) deadline: 13th, Octorber, 2019
